AMS-2624P AV Series 26-port/24 PoE+ Gigabit Managed Switch
The Luxul AV-Series 26-port/24 PoE+ Gigabit Managed Switch (AMS-2624P) features rear panel ports and front facing LEDs (user selectable blue/green colors) for clean integration with AV rack systems. It also features 2 Gigabit RJ-45/SFP Combo ports for easy network expansion. The AMS-2624P is an excellent choice for expanding your network when using PoE-enabled devices such as VoIP, IP cameras and Wireless Access Points. The 26-port Gigabit switch includes 24 PoE+ ports, allowing you to use standard Ethernet cable to deliver both power and high speed data to 802.3af/at-compliant devices. It also features simple-to-use advanced management, VLAN and security capabilities to ensure optimal benefit from your home or office network.
Use the AMS-2624P to
• Add 802.3af/at PoE+ Capability to Your AV Rack Solutions.
• Deliver Power and Data for up to 24 PoE-Enabled Network Devices with a Maximum Output of 250 Watts.
• Simplify PoE Device Installation, Including IP Security Cameras, VoIP Devices, and Wireless APs.
• Optimize and Protect Your Network with Advanced VLAN, QoS and Network Security Featured.
Key Features
• 24 Gigabit RJ45 Ports.
• 2 Gigabit RJ-45 Uplink Ports with 2 Shared SFP Ports (Combo Ports).
• 24 Ports of 802.3af/at PoE+ with 250 Watt Power Budget.
• 52Gbps Switching Capacity.
• 802.1Q VLAN and QoS Support.
• Port Based Authentication.
• Intuitive Management.
• User Selectable Green or Blue Front Facing LEDs.
• Variable Speed Fans for Quiet Operation.
• Standard 19” Rack-Mountable Metal Case.
EAN # : 655003920307
Features |
---|
Committed To Custom | Yes |
Range | AMS |
Number of Ports | 26 |
PoE | 24 x PoE+ |
PoE Budget | 200-300W |
Uplink Ports | 2 x SFP |
Ports Front/Rear | Rear |
Switching Capacity | 52 Gbps |
HD Over IP Compatible | Yes |
Rack Space | 1U |
Dimensions (L x W x H) | 439 x 209 x 44 mm |
Warranty | 3 Year |
